Description
- Available for both US and EU power setups.
- Easy to Use – Push button cable retraction and storage.
- “Zero Effort” Pull-Out – No more heavy pulling!
- Compact – Store power cable in the smallest possible area.
- Easy to Install – No mounting bracket requred, the frame itself offers a variety of mounting options right out of the box.
- Built to Last – Designed to handle any environment on earth!
- Fully Tested and Approved – UL*, CSA*, ABYC, CE, ISO 8846
Customisable Features
- Available for both US and EU power setups
- Available for both 12 & 24 VDC setups
- Designed to handle most 16, 30, & 32 amp power cables (3 or 4 cond.)
- Optional detachable mounting base for a variety of installation options
- Can handle up to 82′ (25m) of cable, dependant upon diameter
- Can handle most cable jacket materials, including S, ST, SE, PUR
| Part Number: | Description: | Input Voltage: | Cable Type: | Plug: | Cable Length: | Color: | Frame / Metal Components: |
| CRMA16-12 | Cordreel – 16amp EU | 12v DC | 16A 250v Superflex | 3 pin Plug IEC60309 | 50′ (15m) | Yellow | Aluminum (Anodized) |
| CRMA16-12-25M | Cordreel – 16amp EU | 12v DC | 16A 250v Superflex | 3 pin Plug IEC60309 | 82′ (25m) | Yellow | Aluminum (Anodized) |
| CRMA16-24 | Cordreel – 16amp EU | 24v DC | 16A 250v Superflex | 3 pin Plug IEC60309 | 50′ (15m) | Yellow | Aluminum (Anodized) |
| CRMA16-24-25M | Cordreel – 16amp EU | 24v DC | 16A 250v Superflex | 3 pin Plug IEC60309 | 82′ (25m) | Yellow | Aluminum (Anodized) |
| CRMA30-12 | Cordreel – 30amp US | 12v DC | 30A 125v (10/3) | Twistlock Plug | 50′ (15m) | White | Aluminum (Anodized) |
| CRMA30-24 | Cordreel – 30amp US | 24v DC | 30A 125v (10/3) | Twistlock Plug | 50′ (15m) | White | Aluminum (Anodized) |
| CRMA30Y-12 | Cordreel – 30amp US | 12v DC | 30A 125v (10/3) | Twistlock Plug | 50′ (15m) | Yellow | Aluminum (Anodized) |
| CRMA32-12 | Cordreel – 32amp EU | 12v DC | 32A 250v Superflex | 3 pin Plug IEC60309 | 50′ (15m) | Yellow | Aluminum (Anodized) |
| CRMA32-24 | Cordreel – 32amp EU | 24v DC | 32A 250v Superflex | 3 pin Plug IEC60309 | 50′ (15m) | Yellow | Aluminum (Anodized) |
Click here to view the CRMA30 brochure.
Click here to view the CRMA16/32 brochure.
